Effective Sensor Size 2/3 inch sensor size when using 4K B4 mount (Actual sensor size 23.10mm x 12.99mm)
Lens Control Electronic control via 12-pin broadcast connector. Control via EF mount pins when using URSA Mini Pro EF Mount with compatible EF lenses.
Sensitivity at 0dB Gain f11 with 2160p59.94. f12 with 2160p50. at 2,000 lux with 89.9% reflectance. additional 1.1 stop light loss using 4K B4 mount.
Focus Focus button triggers auto focus when using compatible lenses with focus servo. Touch and hold on LCD determines focus region and triggers auto focus.
Iris Control Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses so no pixel is clipped in film mode. Scene average auto exposure in video and extended video mode.
Controls Touchscreen menus on 4 inch screen. Push buttons for other controls. 3 assignable shortcut keys and 2 assignable shortcut keys (VTR and RET) on compatible broadcast lenses.
ProRes Shooting Resolutionsand Frame Rates 3840 x 2160 (Ultra HD) up to 60 fps from Ultra HD window or scaled from 5.3Kwindowed sensor 3840 x 2160 (Ultra HD) up to 50 fps scaled from full sensor 1920 x 1080 (HD) up to 120 fps scaled from 2.7K windowed sensor 1920 x 1080 (HD) up to 60 fps scaled from Ultra HD or 5.3Kwindowed sensor 1920 x 1080 (HD) up to 50 fps scaled from full sensor
H.265 Shooting Resolutionsand Frame Rates 3840 x 2160 (Ultra HD) up to 60 fps from Ultra HD window or scaled from 5.3Kwindowed sensor 3840 x 2160 (Ultra HD) up to 50 fps scaled from full sensor
H.264 Shooting Resolutionsand Frame Rates 1920 x 1080 (HD) up to 60 fps scaled from Ultra HD or 5.3K windowed sensor 1920 x 1080 (HD) up to 50 fps scaled from full sensor
Blackmagic RAW Shooting Resolutionsand Frame Rates 6144 x 3456 (6K) up to 50 fps 6144 x 2560 (6K 2.4:1) up to 60 fps 5376 x 3024 (5.3K 16:9) up to 60 fps 3728 x 3104 (3.7K 6:5 anamorphic) up to 60 fps 3840 x 2160 (Ultra HD) up to 60 fps 1920 x 1080 (HD) up to 150 fps
Project Frame Rates 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps. Off-speed frame rates up to 60p in Ultra HD and up to 150p in HD.
Metadata Support Automatically populated lens data from electronic B4 lenses. Automatic recording of camera settings and slate data such as project, scene number, take and special notes.
Analog Audio Inputs 2 x XLR switchable between mic, line and AES digital audio. Phantom power support.
Remote Control 1 x 2.5mm LANC input for Rec Start/Stop, plus Iris and Focus control using compatible lenses.
Computer Interface 1 x USB Type‑C 3.1 Gen 2 with power delivery for external drive recording and connecting Blackmagic Focus and Zoom Demand. 1 x USB Type‑C for software updates.
