Fem modeller!
Ultra Encode familen med live media enkodere gir deg fleksible, pålitelige og kostnadseffektive enkoderings-løsninger for live-streaming, AV over IP, fjernproduksjon og andre arbeidsflyter
Streaming
Visning
Sorter
Nyhet
Nyhet
Velg din Ultra Encode modell
Ultra Encode familien er tilgjengelig i flere modeller for å passe dine behov:
Ultra Encode HDMI/SDI
(Rev B) |
Ultra Encode HDMI/SDI Plus
|
Ultra Encode AIO
|
|
|---|---|---|---|
| Inngang & looptilkoblinger | HDMI (Ultra Encode HDMI) eller SDI (Ultra Encode SDI) | HDMI (Ultra Encode HDMI Plus) eller SDI (Ultra Encode SDI Plus) | HDMI og SDI (encoder 1 inngang ellerkombiner begge til 1 utgang) |
| Maks encoding oppløsning & bitrate (eksludert NDI® HX) |
Main stream: 2048x1080p60 16Mbps
Sub stream: 1080p60 16Mbps
|
Main stream: 4Kp30 32Mbps
Sub stream: 1080p60 32Mbps
|
Main stream: 4Kp30 32Mbps
Sub stream: 1080p60 32Mbps
|
| Audio encoding channels | 2 | 8 | 8 |
| Output audio streams | 1 | 4 | 4 |
| Encoding Formats | H.264, H.265 | H.264, H.265 | H.264, H.265 |
| Streaming Protocols | RTMP, RTMPS, SRT (Caller or Listener), HLS Pull, RTSP, TS over UDP & RTP, TVU ISSP | RTMP, RTMPS, SRT (Caller or Listener), HLS Pull, RTSP, TS over UDP & RTP, TVU ISSP | RTMP, RTMPS, SRT (Caller or Listener), HLS Pull, RTSP, TS over UDP & RTP, TVU ISSP |
| Streaming Presets and Integrations | YouTube via RTMP, Facebook Live, Twitch | YouTube via RTMP or HLS, Facebook Live, Twitch, Wowza over RTMP or SRT | YouTube via RTMP or HLS, Facebook Live, Twitch, Wowza over RTMP or SRT |
| NDI® Support | NDI® HX2 | NDI® HX2, NDI® HX3 | NDI® HX2, NDI® HX3 |
| Simultaneous streaming outputs (*limit 1 output when using NDI® HX) | 6 (using same streaming protocol) | 6 (multiple streaming protocols) | 6 (multiple streaming protocols) |
| Recording | Record to internal storage, external USB drive or NAS | Record to SD card, external USB drive or NAS | |
| Power over Ethernet (PoE) | |||
| Rack mounting | 1RU rackmount shelf and mounting kit (not included) | 1RU rackmount shelf and mounting kit (not included) | Half-width 1RU with included mounting hardware |
