Talkback Audio 1 x 3.5mm stereo connector for talkback microphone. 1 x 3.5mm stereo connector for stereo headphones, compatible with iPhone headsets.
Analog Audio 2 x balanced 1/4" TRS connectors (stereo) microphone level in. When connected, replaces audio from SDI In or HDMI In.
Optical Fiber Audio Input 1 x single mode camera audio inputs with LC connector. Channels 1 & 2 are camera audio. Channels 15 & 16 are intercom audio.
Optical Fiber Audio Output 1 x single mode camera audio outputs with LC connector. Channels 1 & 2 are camera audio. Channels 15 & 16 are intercom audio.
Computer Interface 1 x mini-B type USB 2.0 connector for initial setup, firmware updates and Converter Utility software control. Standards SDI Format Support 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 2K Format Support 1 2K DCI 24p, 2K DCI 25p HDMI Format Support 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 59.94, 60 SDI Compliance SMPTE 259M, SMPTE 292M. Audio Sampling Television standard sample rate of 48Khz,24 bit A/D conversion. Video Sampling 4:2:2 Color Precision 10‑bit Color Space REC 601, REC 709 Multiple Rate support SDI and HDMI are switchable between standard definitlon and high definition Software Software Included Converter Utility. Physical Specifications Environmental Specifications Operating Temperature 0° to 40° C (32° to 104° F) Storage Temperature -20° to 45° C (-4° to 113° F) Relative Humidity 0% to 90% non‑condensing What's Included ATEM Camera Converter Welcome wallet with QR code for software download Warranty 3 Year Limited Manufacturer's Warranty. Excluding connectors, cables, cooling fans, fiber optic modules, fuses, keyboards and batteries which will be free from defects in materials and workmanship for a period of 12 months from the date of purchase.
SDI Format Support 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
HDMI Format Support 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 59.94, 60
Software Included Converter Utility. Physical Specifications Environmental Specifications Operating Temperature 0° to 40° C (32° to 104° F) Storage Temperature -20° to 45° C (-4° to 113° F) Relative Humidity 0% to 90% non‑condensing What's Included ATEM Camera Converter Welcome wallet with QR code for software download Warranty 3 Year Limited Manufacturer's Warranty. Excluding connectors, cables, cooling fans, fiber optic modules, fuses, keyboards and batteries which will be free from defects in materials and workmanship for a period of 12 months from the date of purchase.
