Blackmagic ATEM Talkback Converter 4K

Varenummer:
508845
Produktnummer:
SWRCONVRCKT4K8

inkl. mva.

Description

ATEM Talkback Converter 4K handles up to 8 cameras for SDI talkback using embedded audio channels 15 and 16 as used on the Blackmagic Studio Cameras and ATEM Camera Converter. Supports 12G-SDI for all SD, HD and Ultra HD formats up to 2160p60 and provides BNC connections to each camera, and an optical fiber socket for adding an optical fiber SFP module for extending camera distances when required. Includes push to talk buttons, support for tough and common aviation headsets, loop through for more than 8 camera support, built in speaker, front panel mic input and much more.

Connections

SDI Program Inputs

1 x 10-bit SD/HD/Ultra HD 4K auto switching
program input from switcher, including tally information with 16 channel embedded audio.

Please click here for a summary of recommended cables to use with Blackmagic 12G‑SDI products.

SDI Program Outputs

1 x 10-bit SD/HD/Ultra HD 4K auto switching
program loop thru output connects to another
ATEM Talkback Converter 4K.

Talkback Audio

Aviation Headsets with 0.25" TRS headset
connector and 0.206" TRS microphone connector. Front mounted balanced XLR microphone connector.

Analog Audio

1 x stereo RCA monitoring output.

SDI Camera Inputs

8 x 10-bit SD/HD/Ultra HD 4K auto
switching 16 channel embedded audio.

SDI Camera Outputs

8 x 10-bit SD/HD/Ultra HD 4K auto
switching 16 channel embedded audio.

SDI Outputs

8 x 10-bit SD/HD/Ultra HD 4K auto
switching 16 channel embedded audio.

Optical Fiber Video Inputs (Optional)

8 x single mode SD/HD/Ultra HD 4K auto
switching camera inputs with LC connector.

Optical Fiber Video Outputs (Optional)

8 x single mode SD/HD/Ultra HD 4K auto
switching camera outputs with LC connector.

Optical Fiber Audio Inputs

8 x single mode camera audio inputs with
LC connector. Channels 1 and 2 are camera audio. Channels 15 and 16 are intercom audio.

Optical Fiber Audio Outputs

8 x single mode camera audio outputs with
LC connector. Channels 1 and 2 are camera audio. Channels 15 and 16 are intercom audio.

Computer Interface

1 x mini-B type USB connector for firmware updates.
